PIR detection distance

10m

View angle

110degree

Sensor Type

1/4" Progressive Scan CMOS

Lens

3.6mm

Aperture

F2.1

Low illumination

0Lux

Working Indicator

Red Blue light flashing

Charge indicator

Red Blue light flashing

Standard

2.4G

Mic

≥-38±3dBm

Speaker

8Ω/1W

TF Card

Maximum supports 128G

Button Switch

Reset*1，Ring button *1

Wireless 433MHz

Support

Antenna

3DBi * 1， 433 Ant*1

Battery Type

18650*2

Battery Capacity

5200mAh

Measurement accuracy

High than 5%

Standby life

About 120days (Base on 10times   detection)

Maximum rate

40Mbps

Monitoring distance

Maximum 150m in open area

WIFI standard

IEEE 802.11 b/g/n/ac

Charge Current

1A

Standby power

2.2mW

Operational power consumption

1.1W

Input port

TF Card*1,Micro USB*1,Mic*1,PIR*1,

Output port

Speaker*1；

Key type

Tact Switch*2

Two-Way Talk

Yes

Compression method

G.711a

Video Format

H.264 compression

Video stream

20fps

Frame rate

25/30fps

Android version

Android 4.3 and above

IOS version

IOS 9.X-10.X and above

Cloud recording storage

Support

On line visitor

Maximum 5 people at same time

Remote control and monitoring

Yes

OTA upgrade

Yes

Power Supply

DC 5V 1A

Temperature setting

Temperature：-20 ~ 50 ℃, Humidity <95%
